JAKARTA INDONESIA Sew Gear Motor Seri K PT ALVA PRIMA SEW GEAR MOTOR

Rp. 02
Update Terakhir
29 Nov 2021
Pembelian Min
1 UNIT

Spesifikasi JAKARTA INDONESIA Sew Gear Motor Seri K PT ALVA PRIMA SEW GEAR MOTOR


PT ALVA PRIMA SEW GEAR MOTOR

EMAIL : ALVAPRIMA@CBN.NET.ID



In six single-stage and fourteen two-stage and three-stage sizes, the helical gearmotors by SEW-EURODRIVE ensure an optimum ratio between power and space requirements.



Your advantages

    High torque density

    Long service life

    R37 ... R167 Reduced backlash option

    RM series, specially designed for agitating applications



The tried and tested modular concept and our strict quality criteria allow SEW-EURODRIVE to provide a diverse range of torques and reduction ratios with incomparably finely tuned gradings. With this exceptional diversity, SEW-EURODRIVE sets new standards in the field of drive engineering.

Available versions



    Single-stage or multi-stage

    Foot-mounted or flange-mounted

    Foot-mounted and flange-mounted

    Flange-mounted with extended bearing hub

Helical Gearmotor R Series



RX series (single-stage)

For high output speeds, the exclusively single-stage gear units RX57 to RX107 offer compact solutions for your system design.



Technical data

Gear unit reduction ratio



[i]



1.30 - 8.65

Output torque



[Nm] ([in-lb])



69 - 830 (610 - 7340)

Motor power range



[kW] ([Hp])



0.12 - 45 (0.16 to 60)





Helical Gearmotor R Series



R series (two-stage and three-stage)

Our complete range of helical gearmotors provides the optimum size and power solution for every drive task. And for applications where weight is an issue, our multi-stage gear units provide something special: Thanks to their die-cast aluminum design, the models R07, R17 and R27 are three particularly efficient lightweights – ideal as satellite drives and for use in light machine constructions. Reduced backlash helical gear units are also available


Lihat Selengkapnya

Untuk keterangan lebih lanjut, silahkan download PDF ini :
